SOLAR TRACKER CONTROLLERS





See also: 35% efficiency Concentrator Solar Cells available in stock

WHY TRACK THE SUN?

It is well known that solar "receivers" such are solar cells, solar collectors or any sort of solar concentrators catch more sunbeams if those sunbeams are falling in the right angle onto their surface. But with simple fixed mounting of those solar "receivers" it's impossible to achieve that because sun is moving from east to west every day. Soon you find out that it would be nice to "follow the sun". But how? First you need a structure with one or two actuators capable of moving it by one or ideal by two axis - that is called solar tracker (or sun/solar tracking structure). Then you need solar "receiver" (solar cells, solar collectors, etc) which you mount onto that solar tracker. In the end you only need a device which will be turning on and off tracker's actuator motor(s) so that your solar "receiver" will always catch all available solar energy. Ladies and Gentlemen, the device you need is our FUSIONSEEKER solar tracker controller which was designed to do exactly that.

HOW FUSIONSEEKERs WORK?

FUSIONSEEKER solar tracker controller is (with its light sensors) always looking where the sun is and uses POWER MOS-FET transistors to turn on and off tracker's actuator motor so that solar "receiver" is always facing precisely towards the sun by one axis (in case of non ideal but cheaper "single-axis" tracking) or both axis (in case of ideal "dual-axis" tracking) because we have single and dual-axis controllers available. Motors are being turned on and off throughout the day till sunfall when the tracker stops moving. Next morning when first sun rays appear FUSIONSEEKER with its sensors notices that and immediately turns on the motor to move the tracker to the east. In case when clouds cover the sun it can stop tracking or it can turn solar tracker towards the brightest cloud - that depends on what tracking accuracy you choose (set). And immediately after clouds disappear it will in every case turn the tracker toward the sun. In short, using FUSIONSEEKER you will always ''catch'' the sun.



MAIN FUSIONSEEKER FEATURES AND ADVANTAGES (all models):



UNIVERSAL:

They are designed to be used in all applications that need solar tracking (solar cells trackers, water heating solar collector trackers, any sort of solar concentrator trackers, daylighting systems, etc)

ULTRA RELIABLE:

No moving parts inside of them - 100% solid state electronics (no potentiometers, no relays)

No batteries inside (or other parts that have to be replaced from time to time)

All functions are implemented with pure hardware - no software inside, no computer hang-ups, no reset buttons

EXTREAMLY SIMPLE TO INSTALL

Just mount it and connect supply voltage and motor(s) and....it works....yes, that's ALL

NO computers for setup needed, NO GPS positioning, NO programming

Tracker's motors DO NOT need to be equiped with reed switches, hall sensors, position potentiometers, etc what means no additional wiring

SUPERIOR ELECTRICAL CAPABILITIES

CAN BE POWERED DIRECTLY FROM PV SOLAR PANELS

WIDE INPUT (SUPPLY) VOLTAGE RANGE

HIGH OUTPUT CURRENT

EXTREMELY LOW SUPPLY CURRENT

OUTPUT VOLTAGE:  Uout ≈ Uin

WIDE OPERATING TEMPERATURE RANGE: from -25C to +70C

THEY ALSO HAVE BUILT IN ELECTRONIC BRAKE FOR STOPPING THE MOTOR (must have function for achieving ultra high tracking accuracy)

PREMIUM MODELS CAN TRACK THE SUN WITH ULTRA HIGH TRACKING ACCURACY OF UP TO +0,01 DEGREE

ROBUST WATERTIGHT HOUSINGS

LONG EXPECTED LIFE TIME

100% MAINTENANCE FREE





For more information click on "Products".
